Battery Information
Parameter Name Parameter Description
Working status Indicates the current working status of the
battery, which can be Oine, Idle, Running,
Faulty, or Hibernating.
Working mode Indicates the current working mode of the
inverter battery control.
Charge/Discharge power Total charge and discharge power of all
batteries connected to the inverter.
SOC Indicates the power status of all batteries
connected to the inverter.
Bus voltage Indicates the voltage on the DC bus of the
battery.
Bus current Indicates the current on the DC bus of the
battery.
Rated capacity Total rated capacity of all batteries connected
to the inverter. The rated capacity refers to the
total amount of energy discharged by the
batteries in normal conditions.
Current-day charge capacity Total energy charged into the batteries on the
current day.
Current-day discharge
capacity
Total energy discharged from the batteries on
the current day.
Total charge Total energy charged into the batteries.
Total discharge Total energy discharged from the batteries.
Battery Unit
Parameter Name
Parameter Description
Firmware version Software version of the DC/DC module.
SN Serial number of the DC/DC module.
Working status Indicates the current working status of the
battery unit, which can be Oine, Idle, Running,
Faulty, or Hibernating.
Rated capacity Total amount of energy discharged by the battery
unit in normal conditions.
Voltage Voltage of the battery unit.
Current Current of the battery unit.
SmartLogger3000
User Manual 6 WebUI Operations
Issue 10 (2022-08-20) Copyright © Huawei Technologies Co., Ltd. 142
