Huawei SmartLogger3000 User Manual

Figure 6-62 Device monitoring
Tab Function Description
Running Info. View the running
information about the
custom device.
N/A
Teleindication View the device status,
such as the switch status.
N/A
Telemetering View the real-time
analog data of the
device, such as the
voltage.
N/A
Telecontrol Set the status control
parameters, such as the
parameters for turning
on or o switches.
Set the parameters on
the tab page as required.
Teleadjust Set analog parameters,
for example, set voltage
protection parameters.
Set the parameters on
the tab page as required.
----End
6.3.21 Setting IEC104 Device Parameters
Context
The SmartLogger can connect to third-party devices that support IEC104, such as
the relay protection or monitoring device like the transformer substation. Protocol
information points vary with vendors. Therefore, you need to congure a protocol
information point le in .cfg format and import the le to the SmartLogger for
connecting to a third-party device.
The supported device types are IEC104 device 1 to IEC104 device 5. The
corresponding
conguration le names are iec104_equip_custom_1.cfg to
iec104_equip_custom_5.cfg. Multiple devices of the same type can be connected.
Procedure
Step 1 Congure a protocol information point le in .cfg format and import the le to
the SmartLogger.
SmartLogger3000
User Manual 6 WebUI Operations
Issue 10 (2022-08-20) Copyright © Huawei Technologies Co., Ltd. 185
