Parameter Description
connection port Set the parameter to the AI port for DRM signals.
Startup current range If the current of the AI port is within the setting
range, inverters are turned on. Otherwise, inverters
are turned o.
Power Control Set DI parameters based on the DRM requirements.
----End
6.7.8 Setting Remote Shutdown
6.7.8.1 Setting Dry Contact Remote Shutdown
Context
The SmartLogger has four DI ports, and the OVGR can connect to any DI port. The
SmartLogger shuts down the inverter over OVGR signals.
Figure 6-81 Networking
When setting this function, ensure that the user-dened DI port is not occupied.
Otherwise, the setting will fail.
SmartLogger3000
User Manual 6 WebUI Operations
Issue 10 (2022-08-20) Copyright © Huawei Technologies Co., Ltd. 226
