Figure 3-1 Installation position
3.4 Installing the SmartLogger
The SmartLogger can be wall-mounted or guide rail-mounted.
Wall-mounted installation
● Avoid drilling holes into the water pipes and power cables buried in the wall.
● Install a SmartLogger on a at and secure interior wall.
● When wall-mounting the SmartLogger, ensure that the cable connection area
faces downwards for ease of cable connection and maintenance.
● You are advised to use the tapping screws and expansion tubes delivered with
the SmartLogger.
SmartLogger3000
User Manual 3 Device Installation
Issue 10 (2022-08-20) Copyright © Huawei Technologies Co., Ltd. 31
