Huawei SmartLogger3000 User Manual

Tab Parameter Description
IEC104-N
NOTE
N is 1, 2, 3, 4, or
5.
IEC104-N IP If Link setting is set to
Enable(Limited), set this parameter
based on the IP address of the third-
party management system.
Teleindication
default segment
Set these parameters as required.
NOTE
After the IEC104 conguration le exported
from the SmartLogger and the IEC104
information les delivered with devices are
correctly congured in a third-party
management system, the third-party
management system will be able to monitor
devices connected to the SmartLogger over
the IEC104 protocol.
Telemetry
default segment
Forwarding
Tablecongurati
on
Common
Conguration
Teleindication
default segment
If Link setting is set to
Enable(Unlimited), set these
parameters as required.
NOTE
After the IEC104 conguration le exported
from the SmartLogger and the IEC104
information
les delivered with devices are
correctly congured in a third-party
management system, the third-party
management system will be able to monitor
devices connected to the SmartLogger over
the IEC104 protocol.
Telemetry
default segment
Forwarding
Tablecongurati
on
NO TE
Choose Settings > Other Parameters, and set IEC104 Push Data Period to specify the
interval for the SmartLogger to push data to a third-party management system over
IEC104. If IEC104 Push Data Period is set to 0s, there is no limit on the interval at which
the SmartLogger sends IEC104 data.
----End
6.3.4 Setting RS485 Communications Parameters
Set RS485 parameters and click Submit.
Figure 6-38 Setting RS485 parameters
SmartLogger3000
User Manual 6 WebUI Operations
Issue 10 (2022-08-20) Copyright © Huawei Technologies Co., Ltd. 109
