Button
Button Operation Function Description
RST button Hold down
the button for
1s to 3s.
When WLAN is set to OFF in idle state, hold
down the RST button for 1s to 3s to power on
the WLAN module. The alarm/maintenance
indicator (ALM) then blinks green quickly for 2
minutes (other indicators are o) and the
SmartLogger waits for connecting to the app. If
the app is not connected, the WLAN module is
automatically powered
o after it is powered
on for 4 hours.
Hold down
the button for
more than
60s.
Within 3 minutes after the SmartLogger is
powered on, hold down the RST button for
more than 60s to restart the SmartLogger and
restore factory settings.
Dimensions
Figure 2-8 Dimensions
2.2 SmartModule
2.2.1 Model
Model description
This document covers the following SmartModule model:
● SmartModule1000A01
SmartLogger3000
User Manual 2 Product Overview
Issue 10 (2022-08-20) Copyright © Huawei Technologies Co., Ltd. 20
