Figure 4-4 MBUS networking
Procedure
Step 1 Connect an MBUS cable.
Figure 4-5 Connecting an MBUS Cable
Table 4-1 Components
No.
Component Specications Quantity
1 Busbar
L1/L2/L3
N/A 1
SmartLogger3000
User Manual 4 Cable Connections
