Embroidery Stitch Out Pop-up
Messages
The Embroidery Arm Needs to Calibrate
When the embroidery unit is attached, a pop-up message will
appear and inform you to slide off the hoop and clear the
machine area for calibrating the embroidery arm. You will
also be reminded to attach a suitable embroidery foot.
It is very important to remove the hoop, otherwise the hoop or
the embroidery unit may be damaged while calibrating.
Attach Hoop
If the hoop attached to the machine does not match the
hoop that is selected and displayed on the screen, the
machine will not embroider. You must change the hoop to
the one displayed on the screen or return to embroidery edit
and select the hoop to match the attached hoop.
The hoop needs to be inserted properly for the machine to
detect it. Slide the hoop connector into the hoop attachment
from front to back until it clicks into place.
Bobbin Thread Low
When the bobbin thread is running low, a pop-up message
appears giving you advance notice that you will soon need to
change the bobbin. This gives you an opportunity to plan
when you want to change your bobbin.
It is possible to embroider until the thread has completely
run out. Without closing the pop-up, touch the start/stop
button, or the foot control, to continue embroidering.
Touch cancel to remain at the current stitch position.
Touch OK to move the hoop to the center/remove hoop
position. The hoop position pop-up opens. Replace the
empty bobbin with a full one. Touch current position in the
pop-up and pull back any excess length of needle thread.
Touch the start/stop button to continue embroidering.
Check Upper Thread
The machine stops automatically if the upper thread runs out
or breaks. Re-thread the upper thread from the beginning,
close the pop-up message and then go back a few stitches
using the step stitch-by-stitch control to ensure that the
thread will be secured. Re-start your embroidery.
Change Thread
When it is time to change the upper thread, the machine will
stop. Change the spool of thread and re-thread the machine.
The recommended thread color number is shown in the pop-
up message.
9 Embroidery Stitch Out 143
