Automatic Jump Stitch Trim
When selected, cuts will be automatically performed and
needle thread pulled to the underside of the fabric. This
function saves you time trimming after the embroidery is
completed. The upper thread will be cut and pulled to the
underside of the fabric when starting to embroider after a
color change, at the first color block, after stepping stitches
and when the machine continues to embroider after a jump
stitch.
Thread cuts will be automatically performed in e.g. the
following situations:
• Upper thread is cut automatically and the presser foot
raises at color changes.
• Bobbin thread and upper thread are cut and the presser
foot raises when an embroidery is finished.
• Upper thread is cut automatically at the start of a jump
stitch.
• Cut commands in designs, stitches or programs.
Designs marked with this symbol are
programmed for automatic jump stitch trim.
Jump stitch trim commands can be added to
any design using the complimentary software.
Tip: Hold the thread tail when you start embroidering or at a new color
block so that you can easily remove the thread end when cut.
Tip: If the front and back of your embroidery will be visible, turn off the
automatic jump stitch trim and cut the threads manually.
Tip: If your designs are very close together, e.g. lettering or programmed
stitches, turn off the automatic jump stitch trim and cut the thread
manually.
Twin Needle Options
When a twin needle size is selected the deLuxe™ Stitch
System will automatically use thread tension. When
embroidering with a twin needle the Straight Stitch Plate
needs to be removed as it cannot be used together with a
twin needle. The twin needle setting will automatically be set
when loading a twin needle embroidery project from the
JoyOS ADVISOR™ project menu.
Note: It is very important to activate the twin needle setting when
embroidering with a twin needle to prevent damage to the machine.
11 Settings 159
