CABLE SPECIFICATIONS & ADAPTERS
940043-002 INTEGRATED ENTERPRISE NETWORK 4-3
INTRODUCTION
The Hypercom IEN chassis may be configured for many different networks, each network
requiring several physical interfaces. The following section provides a detailed illustration
of each cable pin connection, pin description and identifies the type of connector used.
In addition, a sample configuration is provided to help you correctly attach the specific
cable to the appropriate IEN chassis connector. The connection on the back of each IEN
chassis corresponds to a port processor. The IEN 1000 connections depend upon whether
your network specifications require use an optional upgrade module. See Chapter 5,
System Configuration for more information about the IEN chassis configurations.
