CABLE SPECIFICATIONS & ADAPTERS
940043-002 INTEGRATED ENTERPRISE NETWORK 4-55
T1/PCM Line Filter
To provide additional surge protection for the IEN chassis network access DTC11-LHO port
processor, an external surge protector is required on each IEN chassis. Install only one
surge protector per IEN chassis. Figure 4-73 illustrates the IEN T1/PCM Line Filter.
Figure 4-73 IEN T1/PCM Line Filter
