CHASSIS PORT PINOUTS
This section describes the pin assignments associated with each of the chassis. The pin
assignments are divided up by connector type, RJ11 and DB25, and interface.
Note: The signal assignments for the IEN chassis port interface connectors are determined by the
port interface card located in the associated card slot.
n
Refer to Chapter 3, Port Processors/Modules for more information about a specific port
processor.
n
Refer to page 2-5, IEN 1000 for more information about the IEN 1000 chassis
specifications.
n
Refer to page 2-8, IEN 2000 for more information about the IEN 2000 chassis
specifications.
n
Refer to page 2-10, IEN 3000 for more information about the IEN 3000 chassis
specifications.
n
Refer to page 2-13, IEN 4000 for more information about the IEN 4000 chassis
specifications.
n
Refer to page 2-17, IEN 5000 for more information about the IEN 5000 chassis
specifications.
T1
Table 2-2 lists the RJ11 pin assignments for a T1 physical interface.
Table 2-2 RJ11 T1
PIN T1 Pin Assignment Key
1 Receive Ring RR
2 Receive TIP RT
3 Transmit Ring TR
4Transmit TIP TT
5Ground T
6RC T1
