INTRODUCTION
940043-002 INTEGRATED ENTERPRISE NETWORK 1-3
IEN HARDWARE REFERENCE
The IEN Hardware Reference is your comprehensive guide to referencing the Hypercom IEN
chassis, port processors and modules, cables and adapters, and system configuration.
The IEN Hardware Reference contains the following chapters:
Chapter 2 - Chassis
This chapter describes the Hypercom solutions for network switches/routers. This chapter
describes the IEN 1000, IEN 2000, IEN 3000, IEN 4000, and IEN 5000 chassis.
Chapter 3 - Port Processors and Modules
This chapter describes the Hypercom port processors and modules. It includes block
diagrams, bus communications, and jumper settings.
Chapter 4 - Cables and Adapters
This chapter describes the Hypercom solutions for connectivity. This chapter includes a
cable matrix and detailed specifications on Hypercom cables and adapters.
Chapter 5 - System Configuration
This chapter describes the Hypercom bus extension and node configuration. It includes bus
clock settings and multi-chassis configurations.
Chapter 6 - IEN 1000 Configuration
This chapter describes the Hypercom IEN 1000 chassis. It includes additional system
configuration examples.
