CHAPTER 2
2-32 IEN HARDWARE REFERENCE 940043-002
RS485 LAN
Table 2-12 lists the DB25 pin assignments for a RS485 LAN physical interface.
Table 2-12 DB25 (RS485 LAN)
Note: The RS485 LAN interface is only used by the IEN 5000 chassis.
PIN RS485 LAN Pin Assignment Key
1Pin not used N/A
2Pin not used N/A
3Pin not used N/A
4Pin not used N/A
5Pin not used N/A
6Pin not used N/A
7Pin not used N/A
8Pin not used N/A
9Pin not used N/A
10 Pin not used N/A
11 Pin not used N/A
12 Pin not used N/A
13 Pin not used N/A
14 Pin not used N/A
15 Pin not used N/A
16 LAN Negative LAN-
17 Pin not used N/A
18 LAN Positive LAN+
19 Pin not used N/A
20 Pin not used N/A
21 Pin not used N/A
22 Pin not used N/A
23 Pin not used N/A
24 Pin not used N/A
25 Pin not used N/A
