10Base-T
Table 2-5 lists the RJ11 pin assignments for a 10Base-T physical interface.
Table 2-5 RJ11 10Base-T
Token Ring UTP
Table 2-6 lists the RJ11 pin assignments for a Token Ring UTP (Unshielded Twisted Pair)
physical interface.
Table 2-6 RJ11 Token Ring UTP
PIN 10Base-T Pin Assignment Key
1 Transmit Positive TX+
2 Transmit Negative TX-
3 Receive Positive RX+
4Pin not used N/A
5Pin not used N/A
6 Receive Negative RX-
PIN T1 Pin Assignment Key
1Pin not used N/A
2Pin not used N/A
3 Transmit Positive TX+
4 Receive Positive RX+
5 Receive Negative RX-
6 Transmit Negative TX-
