Hypercom IEN 1000 - Rs485 Lan

CHASSIS
940043-002 INTEGRATED ENTERPRISE NETWORK 2-27
RS485 LAN
Table 2-7 lists the RJ11 pin assignments for an RS485 LAN physical interface.
Table 2-7 RJ11 RS485 LAN
Note: The RS485 LAN interface is used only by the IEN 3000 chassis.
PIN RS485 Pin Assignment Key
1Pin not used N/A
2LAN Positive LAN+
3Frame Ground GND
4Pin not used N/A
5 LAN Negative LAN-
6Pin not used N/A
