SYSTEM CONFIGURATION

940043-002 INTEGRATED ENTERPRISE NETWORK 6-3

IEN 1000 CONFIGURATION

This section describes the configuration procedures for the IEN 1000 chassis and optional

upgrade modules. Defining the IEN 1000 chassis to IENView is similar to defining an

IEN 2000, IEN 3000, IEN 4000 or IEN 5000 chassis in that, each port is represented by a

unique bus address. However, the bus address for each IEN 1000 chassis port is

preassigned in the IEN 1000 chassis software. Table 6-1 lists the bus address assignments

for the IEN 1000 chassis and optional upgrade modules.

Table 6-1 Bus Address Assignments

Note: These addresses must be used when defining the IEN 1000 chassis to IENView.

Bus Address Port Function

00 WAN

01 Serial Port 1

02 Serial Port 2

03 Serial Port 3

04 Serial Port 4

05 Dial Backup

06 LAN Port (Ethernet or Token Ring)

07 T1

08 HUB

09 MAU

IENView Diagnostics Port (73KS224SL Modem) available for

direct dialup.
