(8) Clamp Filter A
Install the following noise filter to the control power AC cable and motor cable (if there are multiple
axes, connect to the cables of all axes).
Supplier: TDK
Model: ZCAT3035-1330
[Fig. 4] External View of Clamp Filter
(9) Clamp Filter B
Install the following noise filter to the motor power AC cable.
Supplier: Kitagawa Industries
Model: RFC-H13
[Fig. 5] External View of Clamp Filter
Shape/Dimensions
ZCAT Type
To Next Page
