IAI X-SEL User Manual

243
INTELLIGENT ACTUATOR
Part 4 Commands
 WS (Select if true; character)
Command, declaration
Extension condition
(LD, A, O, AB, OB)
Input condition
(I/O, flag)
Command,
declaration
Operand 1 Operand 2
Output
(Output, flag)
Prohibited Prohibited WS
Column
number
Column
number,
character
literal
CP
[Function] This command is used between SLCT and EDSL commands to execute the subsequent
commands up to the next W command or an OTHE or EDSL command when the
comparison result of the character strings in the columns specified in operands 1 and 2
satisfies the condition.
Comparison will be performed for the length set by a SLEN command.
If a character literal is specified in operand 2, comparison will be performed for the entire
length of the literal.
WS
EQ
Operand 1 = Operand 2
NE
Operand 1  Operand 2
[Example 1] SLEN 3 Set the number of comparing characters to 3.
SCPY 1 ‘ABC’ Assign ‘ABC’ to column 1.
LET 1 2 Assign 2 to variable 1.
:
SLCT Execute multi-branching.
WSEQ 1 ‘XYZ’
:
(1)
(1) will be executed if columns 1 to 3 contain ‘XYZ.’
Since columns 1 to 3 contain ‘ABC,’ however, this
command will not be executed.
:
WSEQ 2 *1
:
(2)
:
(2) will be executed if the content of the number of
characters specified by SLEN after column 2 is the
same as the content of the column specified in variable
1.
OTHE
:
(3)
:
EDSL
:
(4)
:
This command will be executed if none of the conditions
are satisfied. In this example, since (2) was executed,
(3) will not be executed.
The processing will move here if any of the conditions
were satisfied and the applicable command executed. In
this example, (2) and (4) will be executed.
* If multiple conditions are likely to be satisfied, remember that the first W will become valid and
any subsequent commands will not be executed. Therefore, state from the command with the most
difficult condition or highest priority.
