INTELLIGENT ACTUATOR
Part 4 Commands
 OTHE (Select other)
Command, declaration
Extension condition
(LD, A, O, AB, OB)
Input condition
(I/O, flag)
Command,
declaration
Operand 1 Operand 2
Output
(Output, flag)
Prohibited Prohibited OTHE Prohibited Prohibited CP
[Function] This command is used between SLCT and EDSL commands to declare the command to be
executed when none of the conditions are satisfied.
[Example 1] Refer to the sections on SLCT, WH and WS.
 EDSL (End selected group)
Command, declaration
Extension condition
(LD, A, O, AB, OB)
Input condition
(I/O, flag)
Command,
declaration
Operand 1 Operand 2
Output
(Output, flag)
Prohibited Prohibited EDSL Prohibited Prohibited CP
[Function] Declare the end of a SLCT command.
[Example 1] Refer to the sections on SLCT, WH and WS.
