■ Antenna memory settings (continued)
D Temporary memory
The antenna temporary memory memorizes the man-
ually selected antenna. The selected antenna will be
re-called even if frequency band has been changed.
q Select the antenna set screen.
w Push [TEMP-M]
F-4
to turn the temporary mem-
ory ON or OFF.
e Select the desired frequency band with a band key.
r Push [ANT]
(MF1) to select the desired antenna.
 •“★” appears when a different antenna from the original
is selected.
t Push [ANT MR]
F-2
to re-call the original antenna.
 •“★” disappears.
y Push
EXIT/SET
toexitantennasetscreen.
CAUTION: Before transmitting with the manually
selected antenna, make sure the selected antenna
is suitable for the operating frequency. Otherwise
the transceiver may be damaged.
D Antenna selection mode
The automatic antenna selection (antenna memory)
and the [ANT] (MF1) switch function can be deacti-
vated if desired.
q Select the antenna set screen.
w Push
[[
ANT
]
SW]
F-6
to select the antenna selec-
tion from Auto, OFF and Manual.
 •Auto :Usetheantennamemory.Antennase-
lection with [ANT] switch is also available.
 •OFF :Onlytheantennaconnectedto[ANT1]
can be used. [ANT] switch is deactivated.
 •Manual:Deactivate theantennamemoryfunc-
tion. Antenna can be selected with [ANT]
switch operation only.
e Push
EXIT/SET
toexitantennasetscreen.
10-4
Push to select the
antenna selection mode.
F-6
[ANT] SW
“�” indicators appear when a different
antenna from the original is selected.
F-4
TEMP-M
to turn thePush
temporary memory ON or OFF.
