Icom IC-7700 - D Quick Tuning Step; D Selecting Khz Step; D Tuning Step Function; Tuning Step Function

3-6
D Quick tuning step
The operating frequency can be changed in larger
steps (0.1, 1, 5, 9, 10, 12.5, 20 or 25 kHz selectable)
for quick tuning.
q Push [TS] to turn the quick tuning function ON.
 •“Z” appears when the quick tuning function is ON.
w Rotate the main dial to change the frequency in
programmed kHz steps.
e Push [TS] again to turn OFF the indicator.
r Rotate the main dial for normal tuning if desired.
3
BASIC OPERATIONS
Quick tuning indicator
D
1
⁄4 tuning step function
When operating in SSB data, CW, RTTY or PSK, the
1
⁄4 tuning function is selectable. Dial rotation is re-
duced to
1
⁄4 of normal speed when the
1
⁄4 tuning func-
tion is ON for finer tuning control.
➥ Push [1/4]
(MF6) to toggle the
1
⁄4 tuning function
ON or OFF.
  •“
1
⁄
4
” appears when the
1
⁄4 tuning function is ON.
D Selecting “kHz” step
q Push [TS] to turn the quick tuning function ON or
OFF.
 •“Z” appears when the quick tuning function ON.
w Hold down [TS] for 1 second to enter quick tuning
step set mode.
 •Selectedtuningstepsforallmodesappear.
e Select the desired operating mode.
r Rotate the main dial to select the desired tuning
step.
t Repeat steps e and r to select quick tuning
steps for other modes, if desired.
y Push
EXIT/SET
toexitthesettingdisplay.
NOTE: When entering quick tuning step set mode,
the quick tuning function must be activated first.
Main dialSelect mode
TS
1/4
1
⁄4 tuning step OFF
1
⁄4 tuning step ON
1 / 4
ON
1 / 4
OFF
