Icom IC-7700

2-1
INSTALLATION AND CONNECTIONS Section 2
■ Unpacking ......................................................................................... 2-2
■ Main dial attachment ........................................................................ 2-2
■ Rack mounting handle detachment .................................................. 2-3
■ Selecting a location .......................................................................... 2-3
■ Grounding ......................................................................................... 2-4
■ Antenna connection .......................................................................... 2-4
■ USB flash drive connection .............................................................. 2-4
■ Required connections ....................................................................... 2-5
D Front panel ................................................................................... 2-5
D Rear panel .................................................................................... 2-5
■ Advanced connections ..................................................................... 2-6
D Front panel ................................................................................... 2-6
D Rear panel—1 .............................................................................. 2-6
D Rear panel—2 .............................................................................. 2-7
■ Linear amplifier connections ............................................................. 2-8
D Connecting the IC-PW1/EURO .................................................... 2-8
D Connecting a non-Icom linear amplifier ........................................ 2-8
■ Transverter jack information ............................................................. 2-9
■ FSK and AFSK connections ............................................................. 2-9
D When using the ACC socket or the microphone connector ......... 2-9
■ Microphones (options) .................................................................... 2-10
D SM-50 ......................................................................................... 2-10
D SM-30 ......................................................................................... 2-10
D HM-36 ......................................................................................... 2-11
■ Microphone connector information ................................................. 2-11
■ Accessory connector information ................................................... 2-12
CAUTION:
The transceiver weighs approximately 22.5 kg
(50 lb). Always have two people available to
carry, lift or turn over the transceiver.
