Icom IC-7700

3-5
■ Frequency setting
The transceiver has several tuning methods for con-
venient frequency tuning.
D Tuning with the main dial
q Push the desired band key on the keypad 1–3
times.
 •Threedifferentfrequenciescanbeselectedoneach
band with the band key.
w Rotate the main dial to set the desired frequency.
If the dial lock function is activated, the lock indica-
tor lights, and the main dial does not function. In
this case, push [LOCK] to deactivate the lock func-
tion. (See page 5-18 for details.)
3
BASIC OPERATIONS
[EXAMPLE]
7.00000 MHz
21.24000 MHz
21.24000 MHz ⇒ 21.36000 MHz
Push
Push
Push
1
1.8
1
1.8
2
3.5
2
3.5
2
3.5
3
7
3
7
4
10
4
10
6
18
6
18
7
21
7
21
8
24
9
28
0
50
ENT
F-INP
ENT
F-INP
ENT
F-INP
ENT
F-INP
ENT
F-INP
ENT
F-INP
ENT
F-INP
GENE
GENE
GENE
850 kHz (0.85000 MHz)
Push
ENT
F-INP
ENT
F-INP
GENE
5
14
8
24
0
50
5
14
Keypad
D Direct frequency entry with the keypad
The transceiver has a keypad for direct frequency
entry as described below.
q Push
F-INP
ENT
.
 •“
F-INP
” indicator appears.
w Input the desired frequency.
 •Push
GENE
•
to input “. (decimal point)” between the
MHz units and kHz units.
e Push
F-INP
ENT
to set the input frequency.
 • Tocanceltheinput,pushanyotherkey(except
∫
or
√
) instead of
F-INP
ENT
.
Band keys
Main dial
