Icom IC-7700 User Manual

4-3
4
RECEIVE AND TRANSMIT
• Speech compressor (p. 6-5)
➥ Push [COMP]
(MF6) to turn the speech compres-
sor ON or OFF.
•Holddown[COMP](MF6) for 1 second to select the
compression bandwidth from wide, middle and nar-
row.
• VOX (voice operated transmit) (p. 6-2)
➥ Push
VOX
 to turn the VOX function ON or
OFF.
•“
VOX
” appearswhentheVOXfunctionisON.
• Transmit quality monitor (p. 6-4)
➥ Push
MONITOR
to turn the monitor function ON
or OFF.
•Rotate[MONIGAIN]toadjustthemonitorgain.
•Monitor indicator (above
MONITOR
switch) lights
when the monitor function is ON.
• Audio tone control (p. 12-5)
➥ Push [SET]
F-7
then [LEVEL]
F-1
to enter
level set mode. Select an item with [Y]
F-1
/
[Z]
F-2
then rotate the main dial to adjust the
audio tone.
D Convenient functions for transmit
D About the 5 MHz frequency band operation (USA version only)
Operation on the 5 MHz frequency band is allowed on
5 discrete frequencies and must adhere to the follow-
ing:
•TheUSB,USB data, CW and PSK modes
•Maximumof100 watts ERP (Effective Radiated Power)
•2.8kHzbandwidth(maximum)
It is your responsibility to set all controls so that trans-
mission in this frequency band meets the stringent
conditions under which amateur operations may use
these frequencies.
NOTE: We recommend that you store these fre-
quencies, modes and filter settings into memory
channels, for easy recall.
To assist you in operating within the rules specified
by the FCC, transmission is illegal on any frequen-
cies other than the five shown in the tables below.
• For the USB and USB data modes
The FCC specifies center frequencies on the 5 MHz
frequency band. However, the transceiver displays
carrier frequency. Therefore, tune the transceiver to
1.5 kHz below the specified FCC channel center fre-
quency.
Transceiver Displayed
Frequency
FCC Channel
Center Frequency
5.33050 MHz 5.33200 MHz
5.34650 MHz 5.34800 MHz
5.35700 MHz 5.35850 MHz
5.37150 MHz 5.37300 MHz
5.40350 MHz 5.40500 MHz
• For the CW and PSK modes
The transceiver displays the center frequency. There-
fore, tune the transceiver to the specified FCC channel
frequency when you operate in these modes.
Transceiver Displayed
Frequency
FCC Channel
Center Frequency
5.33200 MHz 5.33200 MHz
5.34800 MHz 5.34800 MHz
5.35850 MHz 5.35850 MHz
5.37300 MHz 5.37300 MHz
5.40500 MHz 5.40500 MHz

Icom IC-7700 Specifications

General

Modes	SSB, CW, RTTY, AM, FM
Voltage	13.8 V DC ±15%
Output Power	200 W (SSB/CW/RTTY/FM)
Receiver Type	Superheterodyne
Display	7-inch color TFT LCD
Antenna Tuner	Automatic
Image Rejection Ratio	More than 70 dB
IF Frequencies	1st: 64.455 MHz, 2nd: 455 kHz
Selectivity	2.4 kHz (SSB), 500 Hz (CW)
Current Drain	2.5 A (receive)
