Icom IC-7700

16-7
D IP address setting
When updating the firmware from the USB flash
drive, the following settings are not necessary.
IMPORTANT!Afixed(static)IPaddressisusedfor
the IC-7700.
When you connect the IC-7700 to a LAN, ask the
network manager about a usable/assignable IP
address and the subnet mask in advance.
NEVER use an IP address that has already been
used with another device in the network. If the IP
address is duplicated, the network will crash.
q Push
EXIT/SET
several times to close a multi-func-
tion screen, if necessary.
w Push [SET]
F-7
to select set mode menu screen.
e Push [OTHERS]
F-5
to select Others set mode.
r Push [Y]
F-1
or [Z]
F-2
several times to select
“IP Address” item.
t Push [t u]
F-3
to select the desired part then
rotate the main dial to set the desired or specified
IP address.
 •“192.168.0.10”isthedefaultsetting.
y Push [Z]
F-2
to select “Subnet Mask” item.
u Rotate the main dial to set the desired or specified
subnet mask.
 •“255.255.255.0”isthedefaultsetting.
i Push
POWER
to turn the transceiver power OFF,
then ON to enable the IP address and subnet
mask settings.
F-2 F-3F-1
Ω ≈
F-5
OTHERS
EXIT/SET
F-7
SET
∫ √
16
UPDATING THE FIRMWARE
