Icom IC-7700

12-6
12
SET MODE
SSB TBW (WIDE) 100 – 2900
Sets the transmission passband width to a wide
setting by changing the lower and higher cut-off fre-
quencies.
Lower freq. : 100 (default), 200, 300 and 500 Hz
Higher freq. : 2500, 2700, 2800 and 2900 Hz (de-
fault)
SSB TBW (MID) 300 – 2700
Sets the transmission passband width to a middle
setting by changing the lower and higher cut-off fre-
quencies.
Lower freq. : 100, 200, 300 (default) and 500 Hz
Higher freq. : 2500, 2700 (default), 2800 and 2900
Hz
SSB TBW (NAR) 500 – 2500
Sets the transmission passband width to a narrow
setting by changing the lower and higher cut-off fre-
quencies.
Lower freq. : 100, 200, 300 and 500 Hz (default)
Higher freq. : 2500 (default), 2700, 2800 and 2900
Hz
Speech Level 50
%
Sets the side tone output level from 0 to 100% in 1%
steps. (default: 50%)
Side Tone Level 50
%
Sets the side tone output level from 0 to 100% in 1%
steps. (default: 50%)
Side Tone Level Limit ON
Turns the side tone output level limiting capability
ON or OFF. (default: ON)
APF AF Level 0dB
Sets the audio level that the audio peak filter is ON
in the CW mode, from 0 to +6 dB in 1dB step.
(default: 0dB)
Beep Level 50
%
Sets the key-touch beep output level from 0 to 100%
in 1% steps. (default: 50%)
Beep Level Limit ON
Turns the key-touch beep output level limiting capa-
bility ON or OFF. (default: ON)
Phones Level Ratio 1.00
Sets the ratio for audio output level from the head-
phone toward to the internal speaker within a range
of 0.60 to 1.40 in 0.01 steps. (default: 1.00)
■ Level set mode (continued)
