13-3
D Scanning
D Display
D Format USB flash drive
13
MAINTENANCE
PROBLEM POSSIBLE CAUSE SOLUTION REF.
Programmed scan does
not stop.
Programmed scan does
not start.
Memory scan does not
start
Select memory scan does
not start
•Squelchisopen.
•
The same frequencies have been programmed
in scan edge memory channels P1 and P2.
•2 or more memory channels have not been
programmed.
•2 or more memory channels have not been
designated as select channels.
•Set[SQL]tothethresholdpoint.
•Program different frequencies in scan edge
memory channel P1 and P2.
•Programmorethan2memorychannels.
•Designate more than 2 memory channels as
select channels for the scan.
p. 3-9
p. 8-3
p. 8-3
p. 9-7
PROBLEM POSSIBLE CAUSE SOLUTION REF.
The displayed frequency
does not change properly.
•Thediallockfunctionisactivated.
•Asetmodescreenisselected.
•TheinternalCPUhasmalfunctioned.
•
Push [LOCK] to turn the function OFF.
•Push [EXIT/SET]several times toexitthe set
mode screen.
•ResettheCPU.
p. 5-18
p. 12-2
p. 13-7
■ Main dial brake adjustment
The tension of the main dial may be adjusted to suit
your preference.
The brake adjustment is located on the bottom side of
the front panel. See the figure at left.
Slide the brake adjustment to a comfortable tension
level while turning the dial continuously and evenly in
one direction.
Light
Heavy
[MAIN DIAL]
Brake
adjustment
PROBLEM POSSIBLE CAUSE SOLUTION REF.
For mat error appears
when formatting in FAT32
For mat error appears
when formatting in FAT
•The inserted USB flash drive capacity is
smaller than 64 MB.
•The inserted USB flash drive capacity is
larger than 2 GB.
•
Insert a
USB flash drive
larger than 64 MB or
select the FAT format.
•
Insert a
USB flash drive
smaller than 2 GB or
select the FAT32 format.
p. 12-30
p. 12-30
