CONTROL COMMAND
• Operating frequency
Command : 00, 03, 05, 1C 03
q
XXXXX
we
X
rt
XX00
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1000 MHz digit: 0 (Fixed) 100 MHz digit: 0 (Fixed)
• Operating mode
Command : 01, 04, 06
q
XXXX
w
q Operating mode w Filter setting
00: LSB 05: FM 01: FIL1
01: USB 07: CW-R 02: FIL2
02: AM 08: RTTY-R 03: FIL3
03: CW 12: PSK
04: RTTY 13: PSK-R
Filter setting (w) can be skipped with command 01
and 06. In that case, “FIL1” is selected with command
01andthedefaultltersettingoftheoperatingmode
is selected with command 06, automatically.
• Memory keyer contents
Command : 1A 02
X
q: Channel data
01：M1
02：M2
03：M3
04：M4
w–&1: Text data
XXX
……
XX
•Character’scode
Character ASCII code Description
0–9 30–39 Numerals
A–Z 41–5A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
, 2C Symbol
. 2E Symbol
@ 40 Symbol
^ 5E
Example:TosendBT, enter
^BT (5E4254)

2A Inserts contest number (can be
used for 1 channel only)
• Band stacking register
Command : 1A 01
q
XXXX
w
q Frequency band code
Code Freq. band Frequency range (unit: MHz)
01 1.8 1.800000– 1.999999
02 3.5 3.400000– 4.099999
03 7 6.900000– 7.499999
04 10 9.900000–10.499999
05 14 13.900000–14.499999
06 18 17.900000–18.499999
07 21 20.900000–21.499999
08 24 24.400000–25.099999
09 28 28.000000–29.999999
10 50 50.000000–54.000000
11 GENE Other than above
w Register code
Code Registered No.
01 1 (latest)
02 2
03 3 (oldest)
Forexample,whenreadingtheoldestcontentsinthe
21 MHz band, the code “0703” is used.
When sending the contents, the following code should
be added after code w.
e−ui, o!0!1−!3 !4−!6
XX... XXXXXXXXXXXXXXXXXXXXXX XX
q, w
e–u Operating frequency setting
See“•Operatingfrequency.”
i, o Operating mode setting
See“•Operatingmode.”
!0 Data mode setting
1 byte data (XX)
XX
!0
0: OFF, 1: TONE, 2: TSQL
0: OFF, 1: DATA 1, 2: DATA 2, 3: DATA 3
!1–!3 Repeater tone frequency setting
!4–!6 Tone squelch frequency setting
See“•Repeatertone/tonesquelchsetting.”
• Clock 2 offset time setting
Command : 1A 05 0061
X
Shift direction
00: + (plus)
01: − (minus)
Offset time
0000−2400
XXX XX
D Data contents description
