14-9
14
CONTROL COMMAND
D Command table (continued)
Cmd. Sub Cmd. Data Description
1A 05 0224 00, 01 Send/read antenna controller status
(frequency, and so on) data output
from [REMOTE] (00=OFF, 01=ON)
06
see p. 14-11
Send/read DATA mode with filter set
07 00 WIDE selection for SSB transmit
bandwidth
01 MID selection for SSB transmit
bandwidth
02 NAR selection for SSB transmit
bandwidth
08 00 SHARPselectionforDSPltertype
01 SOFTselectionforDSPltertype
09 00 3kHzroonglterselection
01 6kHzroonglterselection
02 15kHzroonglterselection
0A 00 WIDE selection for manual notch width
01 MID selection for manual notch width
02 NAR selection for manual notch width
1B 00
see p. 14-11
Send/read repeater tone frequency
01
see p. 14-11
Send/read TSQL tone frequency
1C 00 00 Send/read transceiver’s status (RX)
When“CI-VOutput(forANT)”
(Command: 1C 04) is set to “ON,”
automatically outputs when changed.
01 Send/read transceiver’s status (TX)
When“CI-VOutput(forANT)”
(Command: 1C 04) is set to “ON,”
automatically outputs when changed.
01 00 Antenna tuner OFF (through)
01 Antenna tuner ON
02 Tuning
02 00, 01 Send/read transmit frequency monitor
setting (00=OFF, 01=ON)
03
see p. 14-10
Read transmit frequency
When“CI-VOutput(forANT)”
(Command: 1C 04) is set to “ON,”
automatically outputs when changed.
04
00
Send/read command to disable to
output the antenna controller status
(frequency and so on) from [REMOTE].
01
Send/read command to enable to
output the antenna controller status
(frequency and so on) from [REMOTE].
1E 00 – Read number of available TX frequency
band
01
see p. 14-12
Read TX band edge frequencies
02 – Read number of user-set TX frequency
band
03
see p. 14-12
Send/read user-set TX band edge
frequencies
21 00
see p. 14-12
Send/read RIT frequency.
01 00, 01 Send/read RIT setting.
(00=OFF, 01=ON)
02 00, 01 Send/read ∂TX setting.
(00=OFF, 01=ON)
25
see p. 14-14
Send/read the selected or unselected
VFOfrequency.
26
see p. 14-14
Send/read the selected or unselected
VFO’soperatingmodeandlter.
To Next Page
