14-8
14
CONTROL COMMAND
Cmd. Sub Cmd. Data Description
1A 05 0177 00/01 Send/read antenna temporary memory
set (00=OFF, 01=ON)
0178 00 to 02 Send/read antenna selection
(00=OFF, 01=Manual, 02=Auto)
0179 00/01 Send/read usage for ANT2
(00=OFF, 01=TX/RX)
0180 00/01 Send/read usage for ANT3
(00=OFF, 01=TX/RX)
0181 00 to 02 Send/read usage for ANT4
(00=OFF, 01=TX/RX, 02= RX)
0182 00 to 20 Send/readVOXdelay
(00=0.0 sec. to 20=2.0 sec.)
0183 00 to 03 Send/readVOXvoicedelay
(00=OFF, 01=Short, 02=Mid., 03=Long)
0184 00 to 09 Send/read NB depth (00=1 to 09=10)
0185 0000 to
0255
Send/read NB width
(0000=0 to 0255=255)
0186 00/01 Send/readexternalkeypadset
for RTTY memory (00=OFF, 01=ON)
0187 00/01 Send/readexternalkeypadset
for PSK memory (00=OFF, 01=ON)
0188 00/01 Voicememorytransmissionsetfor
[F1]– [F4] on the keyboard (00=OFF,
01=ON)
0189 00/01 Memory keyer transmission set for [F1]–
[F4] on the keyboard (00=OFF, 01=ON)
0190 00 Send/read time-out timer OFF
01 Send/read 3 min. time-out timer
02 Send/read 5 min. time-out timer
03 Send/read 10 min. time-out timer
04 Send/read 20 min. time-out timer
05 Send/read 30 min. time-out timer
0191 00 to 06 Send/read APF AF level.
(00=0 dB to 06=+6dB)
0192 0000 to
0255
Send/read LAN MOD output level
(0000=0% to 0255=100%)
0193 00 to 05 Send/read the TX Delay setting (HF)
( 00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)
0194 00 to 05
Send/read the TX Delay setting (50M)
( 00=OFF, 01=10 ms, 02=15 ms,
03=20 ms, 04=25 ms, 05=30 ms)
0195 00, 01 Send/read the Shutdown function.
( 00=Shutdown, 01=Standby/Shut-
down)
0196 0000 to
0223
Send/read the transceive CI-V Ad-
dressforLANtoREMOTEinhexa-
decimal code.
(0000=00h to 0223=DFh)
0197 Send/read the default gateway set
( 0000000000000001=0.0.0.1 to 0255
025502550254=255.255.255.254, or
FF=Blank)
0198 00, 01 Send/read the remote control capabil-
ity. (00=OFF, 01=ON)
0199 000001 to
065535
Send/read the control port setting by
accessing from internet.
(000001=1 to 065535=65535)
0200 000001 to
065535
Send/read the serial port setting by
accessing from internet.
(000001=1 to 065535=65535)
0201 000001 to
065535
Send/read the audio port setting by
accessing from internet.
(000001=1 to 065535=65535)
Cmd. Sub Cmd. Data Description
1A 05 0202 00, 01 Send/read the internet access line
setting.
( 00=FTTH (Fiber To The Home),
01=ADSL/CATV)
0203
see p. 14-14 Send/read Network radio name
(up to 16-character)
0204 00 to 04 Send/readthemaximumAFsample
rates for remote stations.
( 00=8 kHz, 01=12 kHz, 02=16 kHz,
03=24 kHz, 04=48 kHz)
0205 00 to 02 Send/read the AF codecs for remote
stations.
( 00=LPCM 8bit,
01=LPCM 8bit, u-law 8bit,
02=LPCM 8bit, u-law 8bit, LPCM 16bit)
0206 00, 01 Send/read the network TX audio set-
ting for remote stations.
(00=OFF, 01=ON)
0207 00 to 04 Send/readthemaximummodulation
sample rates for remote stations.
( 00=8 kHz, 01=12 kHz, 02=16 kHz,
03=24 kHz, 04=48 kHz)
0208 00 to 02 Send/read the modulation codecs for
remote stations.
( 00=LPCM 8bit,
01=LPCM 8bit, u-law 8bit,
02=LPCM 8bit, u-law 8bit, LPCM 16bit)
0209 00, 01 Send/read the waveform outline indi-
cation on the spectrum scope.
(00=Fill, 01=Fill+Line)
0210
see p. 14-11 Send/read the waveform outline color
for receiving signal.
0211 00, 01 Send/read the waterfall display on the
Spectrum scope. (00=OFF, 01=ON)
0212 00 to 07 Send/read the peak color level for
displaying the waterfall.
00=Grid 1, 01=Grid 2, 02=Grid 3,
03=Grid 4, 04=Grid 5, 05=Grid 6,
06=Grid 7, 07=Grid 8
0213 00, 01 Send/read waveform type on the
Audio FFT scope.
(00=Fill, 01=Line)
0214
see p. 14-11 Send/read waveform color for Audio
FFT scope.
0215 00, 01 Send/read the waterfall display on the
Audio FFT scope. (00=OFF, 01=ON)
0216
see p. 14-11 Send/read waveform color for Audio
Oscilloscope scope.
0217 00, 01 Send/read the voice 1st menu.
(00=VOICE-Root,01=VOICE-PLAY)
0218 01 to 15 Send/read the repeat interval to
transmit the recorded voice audio.
(01=1 sec. to 15=15 sec.)
0219 00, 01 Send/read the recording mode.
(00=TX&RX, 01=RX Only)
0220 00, 01 Send/read the squelch status for the
RX voice audio recording
(00=Always, 01=Squelch Auto)
0221 00, 01 Send/read the QSO audio record file
Split function setting.
(00=OFF, 01=ON)
0222 00, 01 Send/read the PTT Automatic Re-
cording function setting.
(00=OFF, 01=ON)
0223 00 to 03 Send/read QSO PLAY Skip time.
( 00=3 sec., 01=5 sec., 02=10 sec.,
03=30 sec.)
D Command table (continued)
