Icom IC-7700

16-5
!3 After the firmware loading is completed, the trans-
ceiver starts the update automatically and the dia-
log at left is displayed.
RWARNING! NEVER turn the IC-7700 power
OFF at this stage.
The transceiver firmware will be corrupted.
!4 When the dialog disappears, the precaution at left
is displayed.
!5 Read the precaution carefully, and then push
[OK]
F-6
.
 •ReturntoUSB-Memorysetmenu.
!6 Push
POWER
to turn the IC-7700 power OFF, then
ON again.
!7Dependingontheupdate,oneortwodialogboxes
as at left appear in sequence.
RWARNING! NEVER turn the IC-7700 power
OFF at this stage.
The transceiver firmware will be corrupted.
!8 After the dialog disappears, the firmware updat-
ing is completed and normal operation screen ap-
pears.
Please wait for 10sec.
WARNING! NEVER turn power OFF.
Please wait for 25sec.
WARNING! NEVER turn power OFF.
TRX-DSP UPDATING...SCOPE-DSP UPDATING...
16
UPDATING THE FIRMWARE
