7.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible
when the motherboard is outside of the chassis. The table below shows a list of the
peripheral interface connectors on the motherboard. Pinouts of these connectors can be
found in the following sections.
Connector Type Label
Audio connector 4-pin wafer AUDIO_OUT1
Audio out connector 4-pin wafer AMP_OUT1
Battery connector 2-pin wafer BAT1
Clear CMOS button Push button J_CMOS1
DDR4 SO-DIMM slots
260-pin DDR4
SO-DIMM slot
DIMM4, DIMM5
Debug connector 12-pin wafer DBG_PORT1
Inverter connector 6-pin wafer INVERTER1
LVDS connector 40-pin crimp LVDS1
M.2 slot (installed with WLAN module) M.2 A-E key slot M2_CN1
MCU connector 9-pin wafer HOTKEY_CN1
MCU flash connector 10-pin header JP8
MCU flash SPI ROM connector 6-pin wafer MCU_SPI1
Microphone connector 4-pin wafer DMIC1
PCIe Mini card slot (supports mSATA
module)
Half-size PCIe Mini slot M_PCIE1
Power button connector 2-pin wafer PWR_BTN1
Power LED connector 3-pin wafer PW_LED1
RS-232 serial port connector 10-pin header COM2
SATA connector 7-pin connector SATA1, SATA2
SPI flash connector 6-pin wafer JSPI1
TPM connector 20-pin crimp TPM1
