POC-W24C-ULT3 FHD Medical Panel PC
Page 120
7.2.19 USB Connector (RFID_USB1)
PIN NO. DESCRIPTION
1 +5A
2 HUB_D3F-
3 HUB_D3F+
4 GND
Table 7-20: USB Connector (RFID_USB1) Pinouts
7.2.20 USB Connector (TOUCH_USB1)
PIN NO. DESCRIPTION
1 +5A
2 D4F-
3 D4F+
4 GND
Table 7-21: USB Connector (TOUCH_USB1) Pinouts
7.3 External Interface Panel Connectors
The table below lists the rear panel connectors on the POC-W24C-ULT3 panel PC
motherboard. Pinouts of these connectors can be found in the following sections.
Connector Type Label
AT/ATX mode selection switch Switch J_ATX_AT1
Barcode reader connector RJ-11 BAR_CN1
GbE connectors RJ-45 LAN1, LAN2
HDMI output connector HDMI connector HDMI_OUT1
Power connector 4-pin DIN PWR1
Reset button Push button RST1
RS-232/422/485 serial port DB-9 COM1
