POC-W24C-ULT3 FHD Medical Panel PC

Page 117

7.2.11 Power Button Connector (PWR_BTN1)

PIN NO. DESCRIPTION

1 PW_BN

2 GND

Table 7-12: Power Button Connector (PWR_BTN1) Pinouts

7.2.12 Power LED Connector (PW_LED1)

PIN NO. DESCRIPTION

1 PW_LED +5V

2 GND

3 SUS PW LED +5V

Table 7-13: Power LED Connector (PW_LED1) Pinouts

7.2.13 RS-232 Serial Port Connector (COM2)

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

1 -NDCD2 2 -NDSR2

3 NSIN2 4 -NRTS2

5 NSOUT2 6 -NCTS2

7 -NDTR2 8 -XRI2

9 GND 10 N/C

Table 7-14: RS-232 Serial Port Connector (COM2) Pinouts
