IEI Technology POC-W24C-ULT3 User Manual

POC-W24C-ULT3 FHD Medical Panel PC
Page 116
7.2.8 MCU Flash Connector (JP8)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 MCLR 2 +3.3A
3 +5V 4 MCU_IR
5 GND 6 AUTO_CLK
7 ICSPCLK 8 AUTO_DATA
9 ICSPDAT 10 GND
Table 7-9: MCU Flash Connector (JP8) Pinouts
7.2.9 MCU Flash SPI ROM Connector (MCU_SPI1)
PIN NO. DESCRIPTION
1 MCU2_MCLR
2 VCC_MCU2
3 GND
4 MCU2_ICSPCLK
5 MCU2_ICSPDAT
6 NC
Table 7-10: MCU Flash SPI ROM Connector (MCU_SPI1) Pinouts
7.2.10 Microphone Connector (DMIC1)
PIN NO. DESCRIPTION
1 DMIC_CLK
2 DMIC_DATA
3 +3.3V
4 GND
Table 7-11: Microphone Connector (DMIC1) Pinouts
