IEI Technology POC-W24C-ULT3 User Manual

POC-W24C-ULT3 FHD Medical Panel PC
Page 114
7.2.4 Debug Connector (DBG_PORT1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 NC 2 +3.3S
3 GND 4 INT_SERIRQ
5 LPC_AD3 6 LPC_AD2
7 LPC_AD1 8 LPC_AD0
9 FRAME# 10 PLT_RST#
11 PLT_CLK 12 GND
Table 7-5: Debug Connector (DBG_PORT1) Pinouts
7.2.5 Inverter Connector (INVERTER1)
PIN NO. DESCRIPTION
1 +12V
2 +12V
3 ENABKL
4 BRIGHTNESS
5 GND
6 GND
Table 7-6: Inverter Connector (INVERTER1) Pinouts
7.2.6 LVDS Connector (LVDS1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 GND 2 GND
3 A0M_L 4 A1M_L
5 A0P_L 6 A1P_L
7 GND 8 GND
9 A2M_L 10 CLK1M_L
11 A2P_L 12 CLK1P_L
13 GND 14 GND
