POC-W24C-ULT3 FHD Medical Panel PC
Page 53
4.3.3.1.1 Serial Port 1 Configuration
Î Serial Port [Enabled]
Use the Serial Port option to enable or disable the serial port.
Î
Disabled
Disable the serial port
Î
Enabled DEFAULT
Enable the serial port
Î Change Settings [Auto]
Use the Change Settings option to change the serial port IO port address and interrupt
address.
Î
Auto DEFAULT
The serial port IO port address and interrupt
address are automatically detected.
Î
IO=3F8h; IRQ=4
Serial Port I/O port address is 3F8h and the
interrupt address is IRQ4
Î
IO=3F8h;
IRQ=3, 4, 5, 6, 7,
9, 10, 11, 12
Serial Port I/O port address is 3F8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 9, 10, 11,
12
Î
IO=2F8h;
IRQ=3, 4, 5, 6, 7,
9, 10, 11, 12
Serial Port I/O port address is 2F8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 9, 10, 11,
12
Î
IO=3E8h;
IRQ=3, 4, 5, 6, 7,
9, 10, 11, 12
Serial Port I/O port address is 3E8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 9, 10, 11,
12
Î
IO=2E8h;
IRQ=3, 4, 5, 6, 7,
9, 10, 11, 12
Serial Port I/O port address is 2E8h and the
interrupt address is IRQ3, 4, 5, 6, 7, 9, 10, 11,
12
Î Device Mode [RS232]
Use the Device Mode option to set the Serial Port 1 signaling mode.
