IEI Technology POC-W24C-ULT3 User Manual

POC-W24C-ULT3 FHD Medical Panel PC
Page 113
Connector Type Label
USB connectors 4-pin wafer
BT_USB1
CAM_USB1
RFID_USB1
TOUCH_USB1
Table 7-1: Peripheral Interface Connectors
7.2.1 Audio Connector (AUDIO_OUT1)
PIN NO. DESCRIPTION
1 AMP_INL
2 OUT1L
3 OUT1R
4 AMP_INR
Table 7-2: Audio Connector (AUDIO_OUT1) Pinouts
7.2.2 Audio Out Connector (AMP_OUT1)
PIN NO. DESCRIPTION
1 SPK_OUT_P_L
2 SPK_OUT_N_L
3 SPK_OUT_N_R
4 SPK_OUT_P_R
Table 7-3: Audio Out Connector (AMP_OUT1) Pinouts
7.2.3 Battery Connector (BAT1)
PIN NO. DESCRIPTION
1 VBATT
2 GND
Table 7-4: Battery Connector (BAT1) Pinouts
