IEI Technology POC-W24C-ULT3 User Manual

POC-W24C-ULT3 FHD Medical Panel PC
Page 60
Î Stop Bits [1]
Use the Stop Bits option to specify the number of stop bits used to indicate the end of a
serial data packet. Communication with slow devices may require more than 1 stop bit.
Î
1 DEFAULT
Sets the number of stop bits at 1.
Î
2
Sets the number of stop bits at 2.
4.3.6.2 Legacy Console Redirection Settings
The Legacy Console Redirection Settings menu (6BIOS Menu 11) allows the legacy
console redirection options to be configured.
Aptio Setup Utility – Copyright (C) 2016 American Megatrends, Inc.
Advanced
Legacy Serial Redirection Port [COM1] Select a COM port to
display redirection of
Legacy OS and Legacy
OPROM Messages
---------------------
ÆÅ : Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.17.1255. Copyright (C) 2016 American Megatrends, Inc.
BIOS Menu 11: Legacy Console Redirection Settings
Î Legacy Serial Redirection Port [COM1]
Use the Legacy Serial Redirection Port option to specify a COM port to display
redirection of legacy OS and legacy OPROM messages. The options include:
 COM1 D
EFAULT
 COM2
 COM3 (Pci Bus0, Dev0, Func0) (Disabled)
