POC-W24C-ULT3 FHD Medical Panel PC

Page 119

PIN NO. DESCRIPTION PIN NO. DESCRIPTION

13 SCL 14 SDA

15 SB3V 16 SERIRQ

17 GND 18 GLKRUN#

19 LPCPD# 20 LDRQ#

Table 7-17: TPM Connector (TPM1) Pinouts

7.2.17 USB Connector (BT_USB1)

PIN NO. DESCRIPTION

1 +5A

2 HUB_D1F-

3 HUB_D1F+

4 GND

Table 7-18: USB Connector (BT_USB1) Pinouts

7.2.18 USB Connector (CAM_USB1)

PIN NO. DESCRIPTION

1 +5A

2 HUB_D2F-

3 HUB_D2F+

4 GND

Table 7-19: USB Connector (CAM_USB1) Pinouts
