POC-W24C-ULT3 FHD Medical Panel PC
Page 72
4.4.2.1 PCI Express Configuration
Use the PCI Express Configuration submenu (BIOS Menu 22) to configure the PCI
Express slots.
Aptio Setup Utility – Copyright (C) 2017 American Megatrends, Inc.
Chipset
PCI Express Configuration
> M_PCIE1
> M2_CN1
M_PCIE1 Settings.
---------------------
ÆÅ
: Select Screen
↑ ↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Version 2.17.1255. Copyright (C) 2017 American Megatrends, Inc.
BIOS Menu 22: PCI Express Configuration
The M_PCIE1 and M2_CN1 submenus both contain the following options:
Î PCIe Speed [Auto]
Use the PCIe Speed option to configure the PCIe interface speed.
Auto D
EFAULT
Gen 1
Gen 2
Gen 3
Î Detect Non-Compliance Device [Disabled]
Use the Detect Non-Compliance Device option to enable or disable detecting if a
non-compliance PCI Express device is connected to the PCI Express slot.
