POC-W24C-ULT3 FHD Medical Panel PC
Page 41
3.11.2 Arm Mounting
The POC-W24C-ULT3 is VESA (Video Electronics Standards Association) compliant and
can be mounted on an arm with a 75 mm or a 100 mm interface pad. To mount the
POC-W24C-ULT3 on an arm, please follow the steps below.
Step 1: The arm is a separately purchased item. Please correctly mount the arm onto
the surface it uses as a base. To do this, refer to the installation documentation
that came with the mounting arm.
NOTE:
When purchasing the arm please ensure that it is VESA compliant and that
the arm has a 75 mm or a 100 mm interface pad. If the mounting arm is not
VESA compliant it cannot be used to support the POC-W24C-ULT3
medical panel PC.
Step 2: Once the mounting arm has been firmly attached to the surface, lift the panel PC
onto the interface pad of the mounting arm.
Step 3: Align the retention screw holes on the mounting arm interface with those in the
panel PC (
Figure 3-27).
