IEI Technology POC-W24C-ULT3 User Manual

POC-W24C-ULT3 FHD Medical Panel PC
Page 115
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
15 A3M_L 16 A4M_L
17 A3P_L 18 A4P_L
19 GND 20 GND
21 A5M_L 22 A6M_L
23 A5P_L 24 A6P_L
25 GND 26 GND
27 CLK2M_L 28 A7M_L
29 CLK2P_L 30 A8P_L
31 GND 32 GND
33 GND 34 GND
35 PANEL_VCC 36 PANEL_VCC
37 PANEL_VCC 38 PANEL_VCC
39 PANEL_VCC 40 PANEL_VCC
Table 7-7: LVDS Connector (LVDS1) Pinouts
7.2.7 MCU Connector (HOTKEY_CN1)
PIN NO. DESCRIPTION
1 +5V
2 AUTO_DIMMING
3 VOL+
4 VOL-
5 BRIGHT+
6 BRIGHT-
7 LCD ON_OFF
8 N/A
9 GND
Table 7-8: MCU Connector (HOTKEY_CN1) Pinouts
