IEI Technology POC-W24C-ULT3 User Manual

POC-W24C-ULT3 FHD Medical Panel PC
Page 3
1.2 Model Variations
There are three models in the POC-W24C-ULT3 series. All models are preinstalled with
one 4 GB DDR4 memory module and an 802.11a/b/g/n/ac Wi-Fi module. The model
numbers and model variations are listed below.
Model CPU
POC-W24C-ULT3-i7/PC/4G
Intel® Core™ i7-6600U
POC-W24C-ULT3-i5/PC/4G
Intel® Core™ i5-6300U
POC-W24C-ULT3-C/PC/4G
Intel® Celeron® 3855U
Table 1-1: Model Variations
1.3 Features
The POC-W24C-ULT3 features are listed below:
 24” fanless FHD medical-grade panel PC
 Anti-bacteria cover
 Projected capacitive type touchscreen
 Intel® Core™ i7-6600U/i5-6300U or Intel® Celeron® 3855U processor
 Preinstalled with 4 GB of DDR4 memory (system max. 32 GB)
 Two GbE RJ-45 connectors and Wi-Fi 802.11a/b/g/n/ac high speed wireless
 Two internal 3 W speakers
 Four USB 3.0 ports and four USB 2.0 ports
 12 V ~ 28 V wide range DC power input
 One RS-232/422/485 DB-9 connector
 IP 65 compliant front panel
 Optional Mifare RFID reader
 Optional 3-in-1 card reader (supports magnetic stripe card, smart card and
fingerprint)
 Optional VoIP phone handset
 Optional handle module with 1D/2D barcode scanner and reading light
