IEI Technology POC-W24C-ULT3 User Manual

POC-W24C-ULT3 FHD Medical Panel PC
Page 118
7.2.14 SATA Connectors (SATA1 & SATA2)
PIN NO. DESCRIPTION
1 GND
2 TX+
3 TX-
4 GND
5 RX-
6 RX+
7 GND
Table 7-15: SATA Connectors (SATA1 & SATA2) Pinouts
7.2.15 SPI Flash Connector (JSPI1)
PIN NO. DESCRIPTION
1 +V3.3M_SPI_CON
2 SPI_CS#0_CN
3 SPI_SO_SW
4 SPI_CLK_SW
5 SPI_SI_SW
6 GND
Table 7-16: SPI Flash Connector (JSPI1) Pinouts
7.2.16 TPM Connector (TPM1)
PIN NO. DESCRIPTION PIN NO. DESCRIPTION
1 LCLK 2 GND
3 LFRAME# 4 KEY
5 LRERST# 6 +5V
7 LAD3 8 LAD2
9 +3V 10 LAD1
11 LAD0 12 GND
