POC-W24C-ULT3 FHD Medical Panel PC
Page 31
Step 6: After driver installation is complete, push the barcode reader button to trigger the
barcode reader.
Figure 3-13: Barcode Reader Button
WARNING:
Do not stare into beam of the laser light. The human eye can be
damaged. Avoid that the laser beam hits reflective surfaces such as
mirrors, etc. Any changes at the device are forbidden these could
cause a dangerous laser light.
3.6.2 Reading Light
The barcode reader is also equipped with a reading light with 3-level of brightness. Push
the reading light button to turn on or to toggle illumination brightness levels.
Figure 3-14: Reading Light
