Chimp 300 Backpanel
Please make sure the external screen you are about to connect to the console, supports 1920 by 1080
pixels of resolution. Connect it before booting the console.
Fig. 2: Chimp 300 Backpanel
1
Desklight Connector
6
Power Connector
2 Ethernet Port 7 Audio Input
3 USB 2.0 Port 8 Midi Out / Thru / In
4 HDMI Port (External Screen) 9 DMX Ports
5
Desklight Connector
