Infinity Chimp 100 - Basic Concepts; Priority Concept

26
Infinity Chimp Series
Infinity Chimp Series
Special Faders
The far right side of the Chimps frontpanel contains four special master fader controls, each consisting of
a fader and button. These may contain Groups or Special Masters, like Speedmasters. The buttons below
the faders are labeled s1 to s4.
Fig. 7: Special Faders
Touchscreen (Applies to Chimp 300 Console, only)
The 22“ Touchscreen of the Chimp 300 Console is one of the key elements used for user interaction with
the Chimp. It features an easy and intuitive to use graphical user interface.
The Chimp 100 Console does not have an built-in screen, and needs to be connected to an external
screen with full-HD resolution (1920 by 1080) as the userinterface is optimized for that resolution. The
Screen may be a touch screen as well.
