8. The Graphical User Interface
The console utilizes an easy to use and intuitive graphical user interface (GUI). The following sections
explain the basics of finding your way around the GUI, in the internal as well as the external display.
The Screen Layout of the Chimp Consoles is divided into three different parts: The Top Toolbar, the
Content Area and the Bottom Toolbar.
The Top Toolbar the Top Toolbar provides access to the different configuration and programming /
playback views.
Fig. 8: The Graphical User Interface
